**BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.

Description:

• Horsepower and Torque: 610 Horsepower / 525 ft. lbs. Torque
• Cylinder Heads: Gen III Hemi Apache Aluminum Cylinder Heads
• Compression Ratio: 10.48:1
• Gen III Hemi Apache Aluminum Cylinder Heads
• BluePrint Engines Hydraulic Roller Cam
• BluePrint Engines Forged Crank
• BluePrint Engines Forged Pistons


Block:

• NEW “BGE” Hellcat / Apache Engine Block
• 1-Piece Rear Main Seal
• 4-Bolt Main
• 4.090" Bore


Rotating Assembly:

• Forged Crank
• 4.050" Stroke
• 6.125" Connecting Rods
• Forged Pistons
• Internally Balanced Front and Rear


Cylinder Heads:

• Gen III Hemi Apache Aluminum Cylinder Heads
• 73cc Chamber
• 2.140" Intake / 1.650" Exhaust Valves

• Can Accept 6.1, 6.4 or 2009+ 5.7L Intake Manifolds
• Does Not Accept 2008 or Older 5.7L Intakes
• Not Tapped for Stock Hellcat Supercharger. Bolt Pattern Differs from N/A Intake

Cam Specs:

• Hydraulic Roller Cam
• .614 Intake / .614 Exhaust Lift
• 231 Intake / 255 Exhaust Duration
• @.050-115 Degree Lobe Separation


Also Includes:

• GEN III Hemi Compatible Coils - BPP68238603
• Spark Plugs - NGK 97408 / LZTR6AP11EG
• Mid Sump Swap Oil Pan

• Harmonic Balancer

• Timing Cover (Car)
• Valve Covers
• Water Pump

Notes:

• BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
• Features 2013+ 58X reluctor wheel
• Will work with 2009+ ECU as long as paired with 2013+ Crank Sensor.
• 2009+ crankshaft spacing
• 2009+ car timing cover
• VVT locked out
• MDS – eliminated
