**BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty race applications. If this engine is used in a street application our normal 30 month, 50,000-mile warranty applies, if used in sanctioned racing no warranty, expressed, or implied.

Description:

• Horsepower & Torque: 1000 Horsepower / 800 ft. lbs. Torque
• Compression Ratio: 10.65:1
• Brodix SR20 CNC Ported Heads
• Solid Roller Cam
• Mahle Forged Pistons
• Callies Forged Steel Crank

Block:

• BluePrint Engines Cast Iron Block
• Manufactured and Machined in the USA!
• Tall Deck (Cylinder Deck is Approx .400 taller / Wider than OEM Block)

• 1-Piece Rear Main Seal
• 4-Bolt Main
• 4.600" Bore


Rotating Assembly:

• Callies Forged Steel Crank
• 4.750" Stroke
• 6.635" Connecting Rods
• Mahle Forged Pistons
• Internally Balanced Front and Rear


Cylinder Heads:

• Brodix SR20 CNC Ported Heads
• 95cc Chamber
• 2.400" Intake / 1.800" Exhaust Valves
• 440 Intake Runner Volume (cc)


Cam Specs:

• Solid Roller Cam
• .874 Intake / .867 Exhaust Lift
• 293 Intake / 305 Exhaust Duration
• @.050-110 Degree Lobe Separation


Also Includes:

• Holley Sniper Stealth 4500
• BluePrint Engines Intake Manifold
• Moroso Aluminum Oil Pan
• MSD Pro Billet Distributor
• SFI Harmonic Balancer
• Spark Plug and Wires
• Timing Cover


Note:

• For racing or extended wide-open throttle use, race fuel (100+ octane) is required.
• BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
• Oil Requirements: 20W50
